| ITEMS | ExpressBox 1T | ExpressBox 3T |
|---|---|---|
| MODEL | ||
| ExpressBox 1T | Thunderbolt 2 to PCIe Expansion - 1 Slot | Thunderbolt 2 to PCIe Expansion - 3 Slot |
| HARDWARE | ||
| Backplane | 1 PCI Express Slot (For cards that are 7.75" or less) Physical - x16 PCIe 2.0 Electrical - x4 PCIe 2.0 (Thunderbolt spec) |
3 Full-Length PCI Express Slots* one x8 PCIe (slotted to accommodate x16 card) one x8 PCIe one x 4 PCIe Compatible with ALL of card lengths: 1/2 length, 3/4 length and full length |
| Cable | Thunderbolt (Sold Separately) | |
| Interconnect Bandwidth | 20 Gbps Bi-directional | 20 Gbps Bi-directional |
| Hard Drive Support | - | Optional built in drivebay for up to four (4) 2.5" SSD or SAS/SATA drives (when using the drivebay, maximum card length is limited to 8.5") |
| Enclosure | ||
| Material | Heavy-Duty Extruded Aluminum | Aluminum Chassis |
| System Cooling | 2 Fans with Speed Control | 1 Hot Swappable Fan 1 Removable Blower Fan |
| Power Supply | 65W Power Supply / 100-240 VAC, 47-63HZ | 250W, 100-240 VAC, 50-60HZ Two 4-pin auxiliary power tabs |
| Environmental | ||
| Ambient Temperature | 0° to 50° C | |
| Storage Temperature | -20° to 60° C | |
| Relative Humidity | 5% to 85% non-condensing | |
| Package Contents | ||
| Chassis | Power indicator PCI Express card slot opening Thunderbolt 2 ports Power cord socket Easy installation thumbscrew(EB1T Only) |
|
| Hardware Included | Power Supply | Blower (if needed for cooling) Carry Bag U.S. Power Cord |
* 제품의 품질 향상을 위해 예고없이 변경될 수 있습니다.
